SmallRig 3082 Top Handle voor Sony XLR K1M / K2M / K3M en Panasonic DMW XLR1 Adapter 3082

SmallRig Top Handle for Sony XLR-K1M / K2M / K3M and Panasonic DMW-XLR1 Adapter 3082 is designed to hold the camera when equipped with the XLR Microphone adapter as well as provide accessory mounts. The handle is secured to the top of the camera cage via two captive 1/4"-20 screws to prevent twisting and can be moved upwards or downwards by up to 25mm through a knob to fit XLR Microphone Adapter of different heights.

You can adjust it horizontally with a built-in Allen wrench by a maximum of 63mm to find the appropriate center of gravity. Both ends of the handle come with a cold shoe for the mounting microphone, Monitor Mount 2905, and other accessories. Multiple built-in 1/4"-20 threaded holes and ARRI 3/8"-16 locating holes support SmallRig Monitor Mount 2903 and 2904.

Key Features
1. Form-fitting top handle for Sony XLR-K1M, XLR-K2M, XLR-K3M, and Panasonic DMW-XLR1
2. Fits Select SmallRig Sony A7 series and Panasonic camera cage
3. Vertical adjustable for up to 25mm and horizontally adjustable for up to 63mm
4. Built-in cold shoe mounts, 1/4"-20 threaded holes, ARRI 3/8"-16 accessory mounts
5. Integrate Allen wrench for quick release and adjustment.

Note
1.Max Payload: 8kg
2.Please remove the built-in cable clamp of Panasonic DMW-XLR1 before attaching it to the Panasonic GH5 cage CCP2646 and DC-BGH1 cage 3024

Compatibility
Compatible with Sony XLR-K1M / XLR-K2M / XLR-K3M Microphone Adapter
Fits the following Sony cages
Sony Alpha 7R IV cage CCS2416
Sony Alpha 7S III cage 2999, 3193
Sony Alpha 7 III / Alpha 7R III cage 2087, CCS2236, CCS2645, 2176
Sony Alpha 7 II / Alpha 7S II / Alpha 7R II / Alpha 7 III / Alpha 7R III cage 2098, 2238
Sony Alpha 7 III / Alpha 7R III / Alpha 7R IV cage CCS2629
Sony Alpha 7 II cage 2031

Compatible with Panasonic DMW-XLR1 Microphone Adapter
Fits the following Panasonic cages
Panasonic BGH1 cage 3024
Panasonic S5 cage 2983
Panasonic GH5 / 5S cage CCP2646
Panasonic S1 / S1R cage CCP2345
Panasonic S1H cage CCP2488

• 1 x Handle

• Product Dimensions:130.9 x 97 x 40mm
• Package Dimensions: 160 x 120 x 68mm
• Net Weight: 192.5g±5g
• Package Weight: 265g±5g
• Material: Aluminum Alloy
