LAOWA 9mm f/2,8 Zero-D for Fuji X

The 9 mm f/2.8 ZERO-D ultra-wide angle lens is the currently most extreme wide-angle lens with luminosity 2.8 for APS-C cameras. Through his angle of view of 113° it opens photographer extraordinary perspectives.

With a length of 60 mm and only 53 mm, it is ultra compact and with its weight of only 215 grams extremely light. It is the ideal companion for mirrorless system cameras. It fits into any camera bag and feels even in your pocket in good hands.

Thanks to the small front lens are all conventional in filters with only use 49 mm diameter vignetting.
Two aspherical lenses and three lens with ultra-low dispersion both reduce the chromatic aberration as well as optical distortion to an absolute minimum. In addition, excellent sharpness is guaranteed up to the corners by this construction.

The 9 mm f/2.8 ZERO-D is also for video photographer ideal - both from the free hand and with a gimbal. Focusing is done manually, as the aperture setting.

Delivery Contents:
1 x Objective 9mm f/2,8 Zero-D
1 x sunshade
1 x rear cover
1 x front cover

Specifications

focal length	9 mm
Maximum aperture	f/2.8
Minimum aperture	f/22
Diaphragm blades	7
aperture setting	manually
angle of view	113 °
sensor size	APS-C
minimum focusing distance	12 cm
magnification	1:7.5
focusing	manually
Lens construction	15 elements in 10 groups
particularities	extreme angle
filter thread	49 mm
Dimensions (DxL)	58x48 mm
Weight	215 g
housing material	metal

Venus Optics Laowa C & amp, D-Dreamer prime to 9 mm wide-angle lens aperture of f / 2.8 camera bezlusterkowych intended for the APS-C and mount Fujifilm X. Although short focal length provides a very good control of distortion and chromatic aberration and superior the focus from the center to the edge of the frame.
lens offers a wide viewing angle of 113 °, the equivalent focal length of 14 mm full frame. The optical lens system consists of fifteen elements arranged in ten groups. Three low dispersion lens and two aspherical lens provide the highest quality imaging from the center to the edge of the frame. The control of the depth of field corresponding to a 7-blade diaphragm, and a working gradually ring aperture, and the minimum focusing distance of only 12 centimeters. Front element of the lens is covered with a layer of "Frog Eye Coating" to protect against dust and dirt, its low profile and the thread of 49 mm allow installation of filters.
The small size and low weight of the lens - just 215 grams makes it excels in daily use and during shooting using drones and gimbali.

Specification
- model: C & amp, D-Dreamer 9 mm f / 2.8
- fixing Fujifilm X < br /> - the focal length of 9 mm
- angle 113 deg
- minimum aperture f / 2.8
- maximum aperture is f / 22
- the number of diaphragm blades 7
- coating the image APS-C
- optical structure:
