Number of Inputs | Mono (Mic/Line): 8 x Combo XLR-1/4" / 6.35 mm Stereo (Line): 2 x 1/4" / 6.35 mm TRS, 4 x RCA (2 x stereo pairs) |
Number of Outputs | Master Out: 2 x XLR Monitor Out: A-E Monitor A: 2 x 1/4" / 6.35 mm TRS Monitor A-E: 5 x Headphone 1/4" / 6.35 mm TRS |
Input Gain | Pad Off: +16 to +60 dB Pad On: −10 to +34 dB Hi-Z ON: +6 to +50 dB |
Input Impedance | XLR: 3 kOhms TRS: 10 kOhms/1 MOhm (when Hi-Z on) |
Maximum Input Levels | Mono (Mic/Line) Pad Off: 0 dBu (at 0 dBFS) Pad On: +26 dBu (at 0 dBFS) Stereo (Line): +16 dBu |
Phantom Power | 48 V |
Maximum Output Levels | Master Out: +14.5 dBu Monitor A (TRS): +14.5 dBu Monitor A-E (Headphones): 42 mW + 42 mW at 60 Ohms |
Output Impedances | 100 Ohms |
Buses | Master: 1 Monitor: 5 Send EFX: 1 |
Channel Control | Channel Strip Comp: Yes, channels 1 to 8 Low Cut: 75 Hz, 12 dB/oct EQ High: 10 kHz, ±15 dB, shelving Mid: 100 Hz to 8 kHz, ±15 dB, peaking Low: 100 Hz, ±15 dB, shelving |
Level Meters | 12-segment |
Effects | 16 types |
Recorder | Maximum Simultaneous Recording Tracks: 14 at 44.1/48 kHz 12 at 96 kHz Maximum Simultaneous Playback Tracks: 12 Recording Format: WAV 44.1, 48, 96 kHz, 16/24-bit, mono/stereo WAV format Recording Media: 16 MB to 2 GB SD cards 4 to 32 GB SDHC cards 64 to 512 GB SDXC cards |
Audio Interface | 44.1 / 48 kHz Recording: 14 channels Playback: 4 channels Bit depth: 24-bit Interface: USB 2.0 |
Card Reader | SDHC |
USB Host | Class-compliant USB 2.0 high-speed |
Sample Rate (Audio) | 44.1, 48, 96 kHz |
Frequency Characteristics | 44.1 kHz: 20 Hz - 20 kHz (-1.0 dB) 96 kHz: 20 Hz - 40 kHz (-3.0 dB) |
Equivalent Input Noise | Actual Measurements: 128 dB EIN (IHF-A) with +60 dB/150 Ohms input |
Display | LCD with backlight (128×64 resolution) |
Power Supply | AD-19 AC Adapter: 12 VDC / 2 A |
Dimensions (W x D x H) | 17.5 x 11.1 x 2.8" / 445.0 x 282.0 x 70.5 mm |
Weight | 5.6 lb / 2.5 kg |
Вид продукта | Записывающие устройства |
Соединительный штекер | USB |
Соединительный штекер | XLR |
