Saramonic Microphone Adapter SmartRig+ for DSLR and Smartphone

The SmartRig+ from Saramonic is a 2-channel sound adapter, with a total of 6 input ports:

;

;
• 2x XLR
;
• 2x 1/4 6.35mm (for your guitar, etc.)
;
• 2x 3.5mm
;

;

The six input ports are spread out over two channels. Both channels feature 1x XLR, 1x 6.35mm and 1x 3.5mm. You can connect the SmartRig+ to you DSLR camera, GoPro or smartphone (iOS and Android) with the integrated 3.5mm cable. To listen to the sound, you can connect a headphone to the 3.5mm female port. There are two built-in rotary buttons to adjust the input volume.

;

Technical specs SmartRig+

;

The SmartRig+ can be powered with an 9V battery. On the bottom side of the SmartRig+ you will find an 1/4 female screw-thread, to mount him to a camera or tripod. With a button on the top of the SmartRig+, you can turn the 48v phantom power on and off. Because of this, you can use both dynamic and condenser microphones. You can switch between mono and stereo, with the button on the front side.

;

In this video you can find all the details of the SmartRig+:

;

Portable Microphone Guitar Interface

The SmartRig+ makes your recording work easier by connecting professional microphones and guitars (or other instruments) to your smartphone, tablet, DSLR camera or video camera.

2 independent channels allow you to connect and control gain on multiple microphones or guitars at the same time. The interface also features 3 types of input to accommodate any set up: two XLR mic inputs, two 1/4″ (6.35mm) guitar inputs, and two 1/8″ (3.5mm) jack inputs for connecting any instrument or microphone. Outputs to a standard 1.8″ 3.5mm cable for use with, smartphones, cameras and other devices.

Provides 48V phantom power for microphones, and includes a 3.5mm headphone output for real-time sound monitoring. The two gain control thumbwheels make it easy to set precise levels. Toggle between Mono and Stereo output modes as necessary. Powered by one 9V battery.

Key Features

• Two Independent Channels
• Two XLR Microphone Inputs
• Two 3.5mm (TRS) Microphone Inputs
• Two 1/4″ Guitar Inputs
• Output switch for smartphone (TRRS) or Camera/Camcorder/Recorder (TRS)
• 3.5mm Headphone Output Jack for Monitoring
• +48v Phantom Power Switch
• Mono/Stereo Toggle Output Switch

The SmartRig+ from Saramonic is a 2-channel sound adapter, with a total of 6 input ports:

;

;
• 2x XLR
;
• 2x 1/4 6.35mm (for your guitar, etc.)
;
• 2x 3.5mm
;

;

The six input ports are spread out over two channels. Both channels feature 1x XLR, 1x 6.35mm and 1x 3.5mm. You can connect the SmartRig+ to you DSLR camera, GoPro or smartphone (iOS and Android) with the integrated 3.5mm cable. To listen to the sound, you can connect a headphone to the 3.5mm female port. There are two built-in rotary buttons to adjust the input volume.

;

Technical specs SmartRig+

;

The SmartRig+ can be powered with an 9V battery. On the bottom side of the SmartRig+ you will find an 1/4 female screw-thread, to mount him to a camera or tripod. With a button on the top of the SmartRig+, you can turn the 48v phantom power on and off. Because of this, you can use both dynamic and condenser microphones. You can switch between mono and stereo, with the button on the front side.

;

In this video you can find all the details of the SmartRig+:

;

1x SmartRig+ with integrated 3.5mm cable; 1x Bag; 1x Warranty card; 1x Manual; 1x Packaging

The Saramonic SmartRig+ is a portable microphone/guitar interface for recording professional quality audio.

The SmartRig+ makes your recording work easier by connecting professional microphones and guitars (or other instruments) to your smartphone, tablet, DSLR camera or video camera. 2 independent channels allow you to connect and control gain on multiple microphones or guitars at the same time. The interface also features 3 types of input to accommodate any set up: two XLR mic inputs, two 1/4" (6.35mm) guitar inputs, and two 1/8" (3.5mm) jack inputs for connecting any instrument or microphone. Outputs to a standard 1.8" 3.5mm cable for use with, smartphones, cameras and other devices.

Provides 48V phantom power for microphones, and includes a 3.5mm headphone output for real-time sound monitoring. The two gain control thumbwheels make it easy to set precise levels.Toggle between Mono and Stereo output modes as necessary. Powered by one 9V battery.

• Two Independent Channels
• Two XLR Microphone Inputs
• Two 3.5mm (TRS) Microphone Inputs
• Two 1/4" Guitar Inputs
• Output switch for smartphone (TRRS)
• Camera/Camcorder/Recorder (TRS)
• 3.5mm Headphone Output Jack for Monitoring
• +48v Phantom Power Switch
• Mono/Stereo Toggle Output Switch

Specifications:

• Frequency response: 20–20 000 Hz
• Distortion: >0,01% @ 1 kHz
• Signal to noise ratio: 80 dB @ 1 kHz
• Gain: + 20 dB – ∞
• Dimensions: 12 × 4 × 4 cm
• Weight: 130 g

Saramonic SmartRig + is the audio adapter that allows the use of almost any audio equipment with recording devices such as cameras VDSLR, cameras and smartphones.
SmartRig + is equipped with two mini-jack input (3.5 millimeters) and two XLR / Jack (6, 35 millimeter). You can connect mics, guitars console or to a recording device with mini jack (3.5 millimeters). Independent control levels for both of channels, switching between stereo and mono modes, and a headphone jack for listening to facilitate the work with sound. The adapter also provides support phantom powered microphones.
The housing is made of high quality plastic.

Saramonic SmartRig + is the audio adapter that allows the use of almost any audio equipment with recording devices such as cameras VDSLR, cameras and smartphones.
SmartRig + is equipped with two mini-jack input (3.5 millimeters) and two XLR / Jack (6, 35 millimeter). You can connect mics, guitars console or to a recording device with mini jack (3.5 millimeters). Independent control levels for both of channels, switching between stereo and mono modes, and a headphone jack for listening to facilitate the work with sound. The adapter also provides support phantom powered microphones.
The housing is made of high quality plastic.
