Yongnuo YNRay100 LED Lamp - WB (2700 K - 6500 K)

Yongnuo LUX100 RGB LED Lamp

Overview

The Yongnuo LUX100 RGB LED lamp is a compact and versatile light source, ideal for filmmakers and photographers. In the Kit variant, you additionally get a bracket with NP-F battery slots, a diffuser that narrows the light beam to 55, and a carrying case. The lamp is equipped with COB LED technology, allowing you to obtain as many as 36,000 different colors. The device achieves a power of 120 W and a light intensity of 14,000 lux (using the diffuser). A universal Bowens mount and 31 built-in lighting effects are features that will expand the creative ways of working with the lamp. Yongnuo's mobile app support provides remote control and operation within a larger lighting system.

Main Product Features

• Compact LED lamp with 120 W max
• Rich color palette offers up to 36,000 unique colors
• Rec.2020 color space and compliance with the DCI-P3 standard
• Enables light intensity of 14,000 lux from a distance of 1 m (using the included diffuser)
• Adjustable light color temperature from 2000 K to 10000 K
• Included ergonomic handle for comfortable hands-on operation
• Grip equipped with 2 sockets for NP-F battery
• Possibility to connect the handle with a traditional tripod head
• Wide beam angle of 110°
• 31 built-in special effects to expand the creative use of the lamp
• Ergonomic knob responsible for adjusting the brightness and color temperature of the light
• Illuminated LCD display for easy control of settings
• Bowens system adapter allowing connection of popular light modifiers
• Included power adapter and power cable
• Possibility to power the lamp with 2 NP-F batteries (must be purchased separately)
• Support for Yongnuo mobile app (iOS/Android) for remote lamp control
• Operation in a lighting kit on one of 256 channels
• Very quiet fan operation (max. 28 dB)
• Transport case included

Rich Color Palette

The Yongnuo LUX100 RGB LED lamp will allow you to get almost any color of light. The HSI palette offers as many as 36,000 different combinations. The use of the Rec.2020 color space with up to 85% coverage and compliance with the DCI-P3 standard make the richness of colors even greater. This is an excellent choice for professionals who value precision and top-quality light.

Big Power in a Small Package

Looking for a versatile lamp that provides powerful light and won't take up much space? The 120 Watt Yongnuo LUX100 RGB (2000 K - 10000 K) will be perfect for filmmakers and photographers alike. The LED COB technology used makes it possible to achieve impressive light output in a device that measures just 12 x 12 x 12.5 cm. The lamp features a high color rendering index of 96+. The maximum light intensity with a color temperature of 5600 K from a distance of 1 m is 4280 lux. When the included lampshade is attached, this value increases to an impressive 14,000 lux. In addition, the LUX100 RGB consumes significantly less energy than devices with traditional SMD LEDs, which is especially important if you are working with rechargeable batteries and want to enjoy powerful light for as long as possible.

Adjustable Color Temperature

A wide range of color temperature adjustment will allow you to perfectly match the light to the conditions on set. The Yongnuo LUX100 RGB lamp provides adjustment of this parameter in the range from 2000 K to 10000 K. Working with the device, you can also freely reduce or increase the intensity of the light. This kit will open up a whole new range of possibilities for your work on a film or photography set!

Two Power Ways

If you're working at home or in a studio, you can easily connect the lamp to a power outlet using the 19 V / 6.31 A power supply included in the Kit. However, nothing prevents you from taking the device into the field or operating it hand-held to reach all the hard-to-reach places with the light. You can easily connect 2 NP-F batteries (to be purchased separately) to the mount, allowing the device to operate wirelessly!

Remote Control

Convenient operation of the Yongnuo LUX100 RGB flash is provided by a backlit LCD screen, ergonomic dial, and buttons. Thanks to the YONGNUO mobile app, the device can be controlled remotely from up to 50 meters away. This solution will also allow you to establish a connection with other lights, creating an expanded lighting set with access to 256 channels of wireless communication.

Special Effects

Want to spice up your videos with unique special effects without having to go for additional accessories and expensive equipment? The Yongnuo LUX100 RGB LED lamp offers 31 thematic modes that will simulate an ambulance, fire truck, rainbow, pulsating SOS signal, sunset, explosion, or paparazzi camera flashes, among others. You can trigger all effects from the lamp or mobile app. Take advantage of the special modes and see for yourself how the magic of Hollywood works!

Bowens Mount

Thanks to the universal Bowens mounting system, which is extremely popular among filmmakers and photographers, you can easily combine the Yongnuo LUX100 RGB LED flash with light modifiers such as streamers, softboxes, gates, or canopies. In the Kit, you will find one such modifier - a diffuser that will allow you to effectively increase the intensity of the light.

Silence on Set!

When you choose the Yongnuo LUX100 LED flash, you don't have to worry about noise interfering with the video recording process. The device is equipped with extremely quiet fans that adjust to the ambient temperature, measured up to 10 times per second, ensuring perfect precision of operation. The noise level generated by the fans does not exceed 28 dB!

Convenient Transport

Convenient transportation and safe storage are ensured by the sturdy carrying case included with the Yongnuo LUX100 RGB Kit. In it, you will find compartments for the lamp, bracket, and diffuser.

Specifications

• Model: Yongnuo LUX100 RGB Kit
• LED technology used: COB
• Color rendering index (RA): 96+
• Power: 120 W
• Color temperature of light: 2000 K - 10000 K
• Number of predefined special effects: 31
• Angle of light: 110°
• Power supply: DC 19 V / 6.31 A, 2 x NP-F rechargeable battery (must be purchased separately)
• Max remote control range: application (Bluetooth) 50 m, 2.4 GHz 100 m
• Mounting type: Bowens tripod mount compatible with 16mm head
• Estimated lifetime: 50,000 hours
• Dimensions: 12 x 12 x 12.5 cm
• Weight: lamp 1 kg, set 3.31 kg

Set Contents

• Yongnuo LUX100 RGB LED lamp - WB (2000 K - 10000 K)
• Mount with attachment for 2 NP-F batteries
• Transport case
• Lamp diffuser
• Power cable
• Power supply

Photometry

• Light color
• Distance
• No modifier + shade
• 2700 K
• 1 m: 3400 lx, 11100 lx
• 2 m: 950 lx, 2480 lx
• 3 m: 489 lx, 1040 lx
• 5600 K
• 1 m: 4280 lx, 14000 lx
• 2 m: 1180 lx, 3140 lx
• 3 m: 614 lx, 1310 lx
• 6500 K
• 1 m: 4180 lx, 13600 lx
• 2 m: 1140 lx, 3070 lx
• 3 m: 595 lx, 1280 lx
• Red
• 1 m: 600 lx, 1100 lx
• 2 m: 160 lx, 269 lx
• 3 m: 86 lx, 130 lx
• Green
• 1 m: 1020 lx, 1950 lx
• 2 m: 275 lx, 447 lx
• 3 m: 142 lx, 214 lx
• Blue
• 1 m: 397 lx, 863 lx
• 2 m: 107 lx, 195 lx
• 3 m: 55 lx, 90 lx
