Laowa Proteus 2X Anamorphic 85mm T2 - Silver (Meters) VE8520PLEFSM

Laowa Proteus 2X Anamorphic 100mm T2 - Silver (Meters) Arri PL + EF

The Laowa Proteus Cine lenses feature a patented anamorphic design, favored by professionals for their smooth oval bokeh and distinctive flares. With a constant 2x squeeze factor, they achieve an ultra-wide aspect ratio, a standard in the cinema industry.

Images from a 43 sensor yield a 2.661 aspect ratio, while a 65 sensor results in 2.41, both allowing cropping to an ideal 2.391 ratio. The lenses support the S35+ sensor format, covering the Alexa 35 and Red V-Raptor 7K sensors.

The large T2 aperture is ideal for low-light filming, producing sharp images and effectively separating subjects from backgrounds. Optimal image quality is reached at T4, with a close focus distance of just 48 cm, enhancing the characteristic thin and long bokeh of anamorphic lenses.

Laowa offers three flare color options: blue, amber, or silver.

Features

• Patented anamorphic design
• Constant 2x squeeze factor
• Large T2 aperture
• Short close focus distance
• Artistic oval bokeh
• Minimal focus breathing
• Exceptional sharpness
• Full-frame coverage with 1.4x extender
• Professional cine housing
• Available flare colors: silver, blue, amber

Delivery Content

• 1x Proteus 2X Anamorphic 100mm T2 Silver (PL-Mount)
• 1x EF mount
• 1x rear lens cap
• 1x front lens cap
• Shims
• Tools
• Lens support
• Case

Technical Specifications

Focal Length: 100 mm

• 18 lens elements in 14 groups
• Horizontal angle of view: 29.1 degrees
• Vertical angle of view: 12.3 degrees
• Sensor type: S35
• Maximum aperture: T2
• Minimum aperture: T22
• 10 aperture blades
• Manual, stepless aperture adjustment
• Manual focus
• Close focus distance: 99 cm
• Filter thread: 105 mm
• PL mount (EF mount included)
• Dimensions: approx. 11.6 x 24 cm
• Weight: approx. 2800 g
