SmallRig 2386 Verstelbare Monitor Mount voor DJI Ronin S / Ronin SC / Zhiyun Crane 3 / Weebill Lab BSE2386

SmallRig Tilt Monitor Mount for DJI Ronin-S/Ronin-SC/Zhiyun CRANE 3/WEEBILL LAB/WEEBILL-S BSE2386 is designed to hold your monitor onto the handheld stabilizers instead of attaching a plate and then a magic arm. It secures to the side of Zhiyun CRANE 3 and WEEBILL LAB/WEEBILL-S via the integrate rosette directly. For Ronin-S and Ronin-SC, please take off the original focus wheel and attach the rosette plate via two M4 screws. It can support monitor up to 1kg, especially designed for 5”monitor. The monitor arm enables to tilt 180° and it can stop at any position without limitation. There are three 1/4-20 accessory holes and a cold shoe mount for microphone or light. The robust mount features rubber pad to protect your monitor from scratching. Each thumbscrew features holes for hex spanner for further secure.

Key Features:
1. Designed for DJI Ronin-S/Ronin-SC/Zhiyun Crane 3/ Weebill Lab /WEEBILL-S
2. Supports Monitor up to 1kg
3. Tilt 180° with Free-Stop at Any Position
4. 1/4”-20 & Cold Shoe Accessory Mount
5. Features Holes on Each Thumbscrews for Hex Spanner
6. Adjustable Degree of Tightness

Adjustable Monitor Mount for DJI Ronin-S/Ronin-SC/Zhiyun Crane 3/ Weebill Lab

1/4”-20 & Cold Shoe Accessory Mount

Tilt 180° with Free-Stop at Any Position

scenes to be used

Note1: Maximum payload: 1kg
Note2: Please do use the hex spanner to re-tighten the thumbscrew to ensure safe.

Gimbals Compatibility:
DJI Ronin-S
DJI Ronin-SC
Zhiyun WEEBILL-S
Zhiyun WEEBILL LAB
Zhiyun CRANE 3 LAB

Monitor Compatibility：
Any 5”monitor kit Weights less than 1kg
SmallHD Focus Series
SmallHD Focus OLED Series
SmallHD UltraBright Series
SmallHD 500 Series
Atomos Ninja Series
Blackmagic Video Assist 5”
SmallHD 700 Series

Package Includes:
1 x Monitor Mount

Product Dimensions: 128 x 80 x 31.5mm
Package Dimensions: 155 x 80 x 40mm
Net Weight: 125g
Package Weight: 157g
Material(s): Aluminum Alloy

Key Features:

• Designed for DJI Ronin-S/Ronin-SC/Zhiyun Crane 3/ Weebill Lab /WEEBILL-S
• Supports monitor up to 1 kg
• Tilts 180° with free stop in any position
• 1/4"-20 accessory holder and cold socket
• Holes on each screw for hex key
• Adjustable degree of tightening



• Product dimensions: 128 x 80 x 31.5 mm
• Package dimensions: 155 x 80 x 40 mm
• Net weight: 125 g
• Package weight: 157 g
• Material(s): Aluminum alloy
